Eagle 4G63 Stroker 100mm Crankshaft For 7-Bolt (Evo)

Description

Part #: eagCRS 2039375900B7

Crankshaft must be balanced to match your specific rods and pistons.

Eagle forged 4340 steel cranks feature a non-twist forging, .125″ fillet radiuses for superior strength so chamfered / narrowed bearings required, nitrided surface, & micropolished to < 2 ra. Intended for the most demanding applications.

Highlights:

• material: forged 4340 steel
• intended balance: internal
• target bobweight: call
• stroke: 3.937″
• rod journal: 1.771″
• rod journal width: 1.05″
• main journals: 2.244″
• minimum rod length: 5.900″
• typical weight: 34 lbs.
• rear seal diameter: call
• snout diameter: 1.26″
• flywheel bolts: 7
• pilot bore diameter: call
• flywheel register diameter: call
