Manley 86-99 Toyota Celica / 90-99 MR2 3S-GTE DOHC H Beam Connecting Rod Set

Description

Part #: man14008-4

For the budget conscious enthusiast, we also offer our very high quality, yet economical, H-Beam design connecting rods. These are also manufactured from 4340 alloy forgings. They are fully machined, heat treated, stress relieved, shot peened, and magnafluxed. They also are built standard with 3/8″ ARP 2000 bolts.

All Manley connecting rod sets, are weight matched to ± 1.5 grams, big and small end bores are final honed to a tolerance of ± .0002″, critical bend and twist attributes are held to a minimum, and exacting attention is paid to every detail by our final inspection department; thus rendering a finished product that is second to none .

Part # 14008-4

Application’s:

• 3S-GTE motor

Specs:
Center to Center Length — 5.428″

Big End Bore — 2.008″

Big End Width — 1.055″

Pin Diameter — 0.866″ (22mm)

Pin Bore — 0.8671″

Gram Weight — 564
